M & E Equipment Traders

Auto Patty Forming Machine, Hiwell, Patty 100-111
Unit is a stainless steel automatic patty forming machine.
Applications: hamburger patties, chicken nuggets, fish burger patties, potato cake etc.
Technical Details:
Belt width: 130mm
Power: 0.55Kw, 415 Volt
Capacity: 35pcs/min
Chamber Volume: 30 Lt
Product Thickness: 8-15mm
Max Product Dia: 100mm hamburger diameter
Overall Dimension: 860mm L x 600mm W x 1400mm H
Condition: As new, never commissioned
Unit mounted on mobile stand.

HIWELL PATTY 100-111

Incline Cleated Belt Conveyor, Heat & Control, 4000mm L x 875mm W x 2000mm H
Unit is a stainless steel food grade motorised incline belt conveyor.
Infeed height: 875mm
Discharge height: 2000mm
Total travel: 4150mm
Cleat height: 1000mm
Conveyor is directly driven by a 0.55kW @25RPM, 415 Volt gear motor.
Conveyor is fitted with wash spray nozzles.
Conveyor requires 1x section Teflon rail.
approx. 1m long
previously used on snack foods.

HEAT & CONTROL -

Stainless Steel Jacketed Kettle, 300Lt, 820mm Día x 850mm H
Unit is a steam jacketed open top tipping kettle.
Design Code: AS1210-892B
Design Temperature: 150 Celsius
Design Pressure: 1035 KPA Test, 690 KPA working.
Kettle has a dished bottom with 40mm Día discharge.
Kettle has 415 gear motor for tipping.
Overall dimensions: 1400mm L x 1230mm W x 1690mm H.

C.P ENGINEERING -

Plough Shear, Blentech, BT-36072-LZ, 1000 Lt, 1820mm L x 900mm W x 1090mm H
Unit is a stainless steel Blentech Blendtherm blender/cooker.
Machine is ideally suited for preparing sauces, purees, baby foods and other emulsified food products.
Blended is also fitted with an inline emulsifier.
Blender:
Dimensions: 1820mm L x 900mm W x 1090mm H
Diameter of ribbon: 90mm
Ribbon agitator paddle is side scraping.
Discharge is fitted at end wiht a pnuematic foor (440mm L x 190mm W) and also fitted with a 100mm diameter.
Pnuematic valve for pumping out product from the discharge.
Blender is jacketed.
Max working pressure is 90 PSI @ 600 degrees F.
Motor: 7.5kW, 415 Volt gear motor.
Blender fitted with a hinged vacuum capable lid.
Emulsifier:
Inlet/Outlet; 100mm Dia x 50mm
Motor: 7.5kW, 415 Volt
Material: Stainless Steel
Overall measurements: 3550mm L x 1500mm W x 2350mm H

BLENTECH BT-36072-LZ

Cooling Table, 1200mm Diameter
Unit is a stainless steel cooling table.
Table has an adjustable product aeration arm driven by a 0.55kW @ 6.3 RPM, 415 Volt SEW gear motor.
Cooling table is complete with a 4.0kW stainless steel centrifugal fan.
System is set up on a stainless steel forkable frame.
Currently fitted with a 2mm Dia perforated screen.
Overall dimensions: 1700mm L x 1200mm W x 2020mm H

COOLING TABLE -

Vertical Stainless Steel Storage Tank, 3420Lt, 1050mm Dia x 4250mm H straight
Unit is a stainless steel vertical storage tank suitable for dangerous goods storage.
Tank has an enclosed top with conical bottom in skirted frame.
100mm diameter centre discharge.
Tank fitted with level switches and glass inspection window.
Overall height: 5250mm

VERTICAL STORAGE TANK -

Planetary Powder Mixer, Bakermix, , 60Lt
Unit is a stainless steel planetary dough mixer.
Mixer is 3 speed and is supplied with 2x mixing arm attachments.
Power Input: 2.2kW
Voltage: 415 Volt
Dimensions of Bowl: 470mm Dia x 450mm H
Manual lift & Manual timer.
Bread dough: 37kg
Pizza dough: 34kg.

BAKERMIX SP-60A-G

Stainless Steel Jacketed Kettle, C.P Engineering, 300 Lt, 820mm Día x 850mm H
Unit is a steam jacketed open top tipping kettle.
Design Code: AS1210-892B
Design Temperature: 150 Celcius
Design Pressure: 1035 KPA Test, 690 KPA working.
Kettle has a dished bottom with 40mm Dia discharge.
Kettle has 415 gear motor for tipping.
Overall dimensions: 1400mm L x 1230mm W x 1690mm H.

Powder Mixer, Ribbon Blender, 1000 Lt, 1540mm L x 950mm W x 1070mm H
Unit is a dimple jacketed insulated twin ribbon blender.
Ribbon diameter: 920mm
Blender is a chain driven by a 4kW gear motor, 415 Volt.
Blender has a 150mm diameter side discharge reduced down to 50mm.
Blender has a hinged lid.

RIBBON BLENDER CAPACITY: 1000LT.

Glass Lined Jacketed Mixing Batch Reactor, Capacity: 6,300Lt, Dimension: 2100mm Dia x 1860mm H

DE DIETRICH 6,300LT

Vibratory Conveyor, Heat & Control, Fastback (CV-FB-260E-G3), 4570mm L x 510mm W x 830mm H
Unit is a stainless steel horizontal conveying system.
Previosuly used in the snackbrand industry on chips.
Conveyor is driven by a 2.0HP, 415 Volt electric motor.
Year: 2019
Height of Tray: 190mm

HEAT & CONTROL FASTBACK (CV-FB-260E-G3)

Air Compressors, Brand: Atlas Copco, Model: G15FFA10.5TM OP, Capacity: 77.5CFM
Unit is a screw air compressor fitted with air dryer & receiver.
Capacity: 77.5CFM.
Motor: 15kw, Voltage: 415volt
Max Pressure: 10.25 Bar.
Year: 2017, CFM: 77.5
Serial # WU X 773191, Approx: 11000.
Overall dimension approx: 1800mm L x 750mm W x 1800mm H.

ATLAS COPCO G15FFA10.5TM OP
