M & E Equipment Traders

Auto Patty Forming Machine, Hiwell, Patty 100-111
Unit is a stainless steel automatic patty forming machine.
Applications: hamburger patties, chicken nuggets, fish burger patties, potato cake etc.
Technical Details:
Belt width: 130mm
Power: 0.55Kw, 415 Volt
Capacity: 35pcs/min
Chamber Volume: 30 Lt
Product Thickness: 8-15mm
Max Product Dia: 100mm hamburger diameter
Overall Dimension: 860mm L x 600mm W x 1400mm H
Condition: As new, never commissioned
Unit mounted on mobile stand.

HIWELL PATTY 100-111

Vibratory Conveyor, TNA, VM3, 2450mm L x 1000mm W x 1390mm H
Unit is a heavy duty stainless steel vibratory conveyor previously used in the snack food industry on chips.
Height of tray: 400mm
Conveyor is fitted with TNA speed controller model # VCE-15 SXWXW
Overall dimensions: Approx. 2600mm L x 1260mm W x 1900mm H

TNA VM3

Vertical Stainless Steel Storage Tank, 3420Lt, 1050mm Dia x 4250mm H straight
Unit is a stainless steel vertical storage tank suitable for dangerous goods storage.
Tank has an enclosed top with conical bottom in skirted frame.
100mm diameter centre discharge.
Tank fitted with level switches and glass inspection window.
Overall height: 5250mm

VERTICAL STORAGE TANK -

Vibratory Conveyor, Heat & Control, Fastback (CV-FB-260E-G3), 4570mm L x 510mm W x 830mm H
Unit is a stainless steel horizontal conveying system.
Previosuly used in the snackbrand industry on chips.
Conveyor is driven by a 2.0HP, 415 Volt electric motor.
Year: 2019
Height of Tray: 190mm

HEAT & CONTROL FASTBACK (CV-FB-260E-G3)

Plough Shear, Blentech, BT-36072-LZ, 1000 Lt, 1820mm L x 900mm W x 1090mm H
Unit is a stainless steel Blentech Blendtherm blender/cooker.
Machine is ideally suited for preparing sauces, purees, baby foods and other emulsified food products.
Blended is also fitted with an inline emulsifier.
Blender:
Dimensions: 1820mm L x 900mm W x 1090mm H
Diameter of ribbon: 90mm
Ribbon agitator paddle is side scraping.
Discharge is fitted at end wiht a pnuematic foor (440mm L x 190mm W) and also fitted with a 100mm diameter.
Pnuematic valve for pumping out product from the discharge.
Blender is jacketed.
Max working pressure is 90 PSI @ 600 degrees F.
Motor: 7.5kW, 415 Volt gear motor.
Blender fitted with a hinged vacuum capable lid.
Emulsifier:
Inlet/Outlet; 100mm Dia x 50mm
Motor: 7.5kW, 415 Volt
Material: Stainless Steel
Overall measurements: 3550mm L x 1500mm W x 2350mm H

BLENTECH BT-36072-LZ

Incline Belt Conveyor, Heat & Control, 2500mm L x 460mm W x 1200mm H
Unit is a stainless steel food grade motorised incline belt conveyor with Intralox belting.
Conveyor is fitted with large infeed hopper.
Infeed height to top of the hopper: 1250mm
Discharge height from bottom of chute: 1200mm
Conveyor is directly driven by a 0.75kW @ 15RPM, 415 Volt electric gear motor.
Previously used on fresh produce.

HEAT & CONTROL -

Incline Cleated Belt Conveyor, Heat & Control, 4000mm L x 875mm W x 2000mm H
Unit is a stainless steel food grade motorised incline belt conveyor.
Infeed height: 875mm
Discharge height: 2000mm
Total travel: 4150mm
Cleat height: 1000mm
Conveyor is directly driven by a 0.55kW @25RPM, 415 Volt gear motor.
Conveyor is fitted with wash spray nozzles.
Conveyor requires 1x section Teflon rail.
approx. 1m long
previously used on snack foods.

Ribbon Blender, Mackies, 2000 Lt, 2350mm L x 1610mm W x 1080mm H
Unit is a twin shaft ribbon blender.
Diameter of ribbons: 770mm each.
Blender is driven by a 2 x 15kW @ 553 RPM, 415 VoH gear motors.
Blender has 2x Pneumatic door end discharges.
Outlet: 560mm L x 245mm W each

MACKIES -

Glass Lined Jacketed Mixing Batch Reactor, Capacity: 6,300Lt, Dimension: 2100mm Dia x 1860mm H

DE DIETRICH 6,300LT

Stainless Steel Jacketed Kettle, 300Lt, 820mm Día x 850mm H
Unit is a steam jacketed open top tipping kettle.
Design Code: AS1210-892B
Design Temperature: 150 Celsius
Design Pressure: 1035 KPA Test, 690 KPA working.
Kettle has a dished bottom with 40mm Día discharge.
Kettle has 415 gear motor for tipping.
Overall dimensions: 1400mm L x 1230mm W x 1690mm H.

C.P ENGINEERING -

Stainless Steel Jacketed Vertical Tank, 500 Lt, 100mm Dia x 650mm H straight
Unit is a heavy duty stainless steel pressure vessel with coil external jacket.
Tank gas an enclosed dished top with bolted top manway.
Dished bottom with 25mm diameter center discharge.
Working pressure: 15 PSI
Overall height: 1700mm

Stainless Steel Jacketed Kettle, C.P Engineering, 300 Lt, 820mm Día x 850mm H
Unit is a steam jacketed open top tipping kettle.
Design Code: AS1210-892B
Design Temperature: 150 Celcius
Design Pressure: 1035 KPA Test, 690 KPA working.
Kettle has a dished bottom with 40mm Dia discharge.
Kettle has 415 gear motor for tipping.
Overall dimensions: 1400mm L x 1230mm W x 1690mm H.
